The QT18-15 floor block making machine is equipped with an imported high-efficiency hydraulic proportional system featuring pure components. This advanced system delivers more efficient power transmission and significant energy conservation compared to conventional hydraulics. The proportional control enables precise adjustment of pressure and flow according to real-time production demands, reducing wasteful energy consumption while maintaining strong compaction force. Operators benefit from smoother, more responsive machine actions, faster cycle times, and lower operating costs. This reliable hydraulic solution ensures consistent block quality and extended component life for continuous floor block production.
Model :
Yixin Machinery QT18-15Machine Dimension :
12500*2714*3100Pallet Size :
1350*1350mmCycle Time :
15-25（S）Vibration Force :
105(KN)Vated Pressure :
21（mpa）Power :
81.38(KW)Quality Service Floor Block Making Machine QT18-15
Reference video of QT18-15 floor block making machine
The QT18-15 floor block making machine is equipped with a PLC control unit that manages all equipment actions and the complete production process. This intelligent system precisely coordinates material feeding, vibration, hydraulic compression, mould movement, and block ejection. The PLC ensures consistent cycle timing, accurate parameter adjustments, and real-time monitoring of every stage. Its user-friendly interface allows operators to easily modify settings for different floor block designs.
Production Data
| Block Type | Specification（mm） | Qty/Palllet | Qty/Hour | Qty/Hours |
| Hollow Block | 400*200*200 | 18 | 2592 | 20736 |
| Solid Block | 240*115*53 | 100 | 25000 | 200000 |
| Holland Block | 200*100*60 | 66 | 10625 | 85000 |
| Zigzag Block | 225*112.5*60 | 50 | 9000 | 72000 |
Product Detail
Block Display
The PLC control unit on the QT18-15 floor block making machine manages all equipment actions and production processes with precision. It automatically coordinates material feeding, vibration, compression, mould movement, and block ejection in the correct sequence. Operators can easily adjust cycle times and block parameters through the user-friendly interface. The system monitors performance in real time, reducing manual intervention and preventing operational errors. This intelligent control ensures consistent block quality, maximizes production efficiency, and minimizes downtime, making the QT18-15 reliable for continuous, high-output floor block manufacturing with minimal labor requirements.
The hydraulic unit of the QT18-15 floor block making machine supplies reliable hydraulic power to enable every machine action. It drives critical operations including material compression, mould clamping, lifting, and block ejection with consistent force and precision. The unit is engineered for continuous heavy-duty use, featuring efficient flow control and pressure regulation. This ensures smooth, synchronized movements of all hydraulic components, reducing cycle times and mechanical stress. Operators benefit from responsive control and low maintenance needs, making the hydraulic unit essential for achieving high output, uniform block density, and durable performance in floor block production.
| FAQ |
|
1.How long does the product production cycle typically take? Quality Service Floor Block Making Machine QT18-15 can produce a variety of products including external wall blocks, internal wall blocks, PC stone permeable bricks, flower wall blocks, floor blocks, dike blocks, chain blocks, curbs, and other types of blocks.The production time for brick making machines is generally 25-30 working days, depending on the customer's production line requirements. |
|
2. How many days to change vibration box oil ,what kind of oil can be used inside? The hydraulic oil 68 degree can be used, the amount is from bottom 3cm. Strongly suggest 1 month change one time oil. |
|
3.What are the raw materials used in the production process of Yixin Machinery Quality Service Floor Block Making Machine QT18-15? The raw materials utilized in the production process of Quality Service Floor Block Making Machine QT18-15 primarily include sand, gravel, and cement. Additionally, this machine has the capability to incorporate a significant amount of industrial waste materials such as slag, coal gangue, clay, ceramisite, perlite, and others. |
|
4.What is the estimated date of shipment for the Quality Service Floor Block Making Machine QT18-15 after mold confirmation? The estimated date of shipment for the Quality Service Floor Block Making Machine QT18-15 is 25-30 working days following the confirmation of the mold. This timeframe allows for the necessary preparations, assembly, and quality checks to ensure that the machine is ready for dispatch and meets the customer's specifications. |
|
5. Can the Quality Service Floor Block Making Machine QT18-15 be equipped with an additional device to produce various types of colored paving blocks?
Yes, the Quality Service Floor Block Making Machine QT18-15 can indeed be upgraded or equipped with a secondary materials device that allows for the production of a wide range of colored paving blocks. |
