Premium Quality Automatic Concrete Block Forming Machine QT6-15
The QT6-15 delivers high efficiency with low energy consumption, producing up to 8640-11520 hollow blocks per hour. Its fully automatic PLC system ensures precise control and easy operation. Robust vibration and hydraulic system guarantee dense, uniform blocks. Quick mould change allows versatile production of paving stones, hollow blocks, and more. Durable construction reduces maintenance costs. Ideal for medium-scale operations seeking reliable, cost-effective concrete block solutions.
Model :
Yixin Machinery QT6-15Machine Dimension :
9450*3300*2700Pallet Size :
880*680/980*680（MM）Cycle Time :
15-25（S）Vibration Force :
68（KN）Vated Pressure :
21（mpa）Power :
31.4（KW）Premium Quality Automatic Concrete Block Forming Machine QT6-15
Reference video of QT6-15 concrete block making machine
The QT6-15 delivers high efficiency with a cycle time of 15-25 seconds, producing 6 hollow blocks per mold. Its advanced vibration system ensures superior block density and strength. The fully automatic PLC control simplifies operation, reducing labor costs. Durable construction with wear-resistant molds extends service life.
Production Data
| Block Type | Specification（mm） | Qty/Palllet | Qty/Hour | Qty/Hours |
| Hollow Block | 400*200*200 | 6 | 1080 | 8640-11520 |
| Solid Block | 240*115*53 | 32 | 7680 | 46080-61440 |
| Holland Block | 200*100*60 | 21 | 3780 | 30420 |
| Zigzag Block | 225*112.5*60 | 20 | 3600 | 28800 |
Product Detail
Block Display
Our products utilize an arch-breaking rapid material distribution device and an extended high-efficiency true-multiple technology, resulting in shorter molding times, higher density, and more uniform material distribution for porous bricks.
Customers Access
Our products are produced on fully automated production lines and can be customized to meet the production needs and site conditions of customers in various countries, thereby improving production efficiency, reducing labor costs, and addressing customer concerns.
| FAQ |
|
1.How long does the product production cycle typically take? Premium Quality Automatic Concrete Block Forming Machine QT6-15 can produce a variety of products including external wall blocks, internal wall blocks, PC stone permeable bricks, flower wall blocks, floor blocks, dike blocks, chain blocks, curbs, and other types of blocks.The production time for brick making machines is generally 25-30 working days, depending on the customer's production line requirements. |
|
2. How many days to change vibration box oil ,what kind of oil can be used inside? The hydraulic oil 68 degree can be used, the amount is from bottom 3cm. Strongly suggest 1 month change one time oil. |
|
3.What are the raw materials used in the production process of Yixin Machinery Premium Quality Automatic Concrete Block Forming Machine QT6-15? The raw materials utilized in the production process of Premium Quality Automatic Concrete Block Forming Machine QT6-15 primarily include sand, gravel, and cement. Additionally, this machine has the capability to incorporate a significant amount of industrial waste materials such as slag, coal gangue, clay, ceramisite, perlite, and others. |
|
4.What is the estimated date of shipment for the Premium Quality Automatic Concrete Block Forming Machine QT6-15 after mold confirmation? The estimated date of shipment for the Premium Quality Automatic Concrete Block Forming Machine QT6-15 is 25-30 working days following the confirmation of the mold. This timeframe allows for the necessary preparations, assembly, and quality checks to ensure that the machine is ready for dispatch and meets the customer's specifications. |
|
5.Can this machine make my bricks or bricks of other sizes?
We will design and make mold according to customer's drawing. |
