Factory Direct Sale Hydraulic Porous Hollow Block Making Machine QT8-15
The QT8-15 is a hydraulic, high-efficiency machine engineered for producing porous hollow blocks with excellent strength and permeability. Designed for factory direct sale, it offers exceptional value with robust construction, a high-frequency vibration system, and PLC intelligent control. The machine delivers consistent density, sharp edges, and precise dimensions for drainage-friendly blocks ideal for landscaping, parking lots, and ecological projects. With quick mold change capability, it also produces standard hollow blocks, solid bricks, and pavers. Backed by direct factory support, the QT8-15 provides reliable performance, low maintenance, and rapid return on investment for block manufacturers worldwide.
Model :
Yixin Machinery QT8-15Machine Dimension :
9800*3600*2800(MM)Pallet Size :
940*860(MM)Cycle Time :
15-20(S)Vibration Force :
95(KN)Vated Pressure :
21(MPA)Power :
31.7(KW)Factory Direct Sale Hydraulic Porous Hollow Block Making Machine QT8-15
Reference video of Factory Direct Sale Hydraulic Porous Hollow Block Making Machine QT8-15:
This reference video showcases the QT8-15, a hydraulic porous hollow block making machine available for factory direct sale. Engineered for high-efficiency production, it delivers porous blocks with excellent strength, permeability, and precise dimensions. Featuring a high-frequency vibration system, PLC intelligent control, and quick mold change capability, the machine produces drainage-friendly blocks ideal for landscaping, parking lots, and ecological projects. It also manufactures standard hollow blocks, solid bricks, and pavers. Backed by direct factory support, the QT8-15 offers reliable performance, low maintenance, and rapid ROI. Watch the video to see the QT8-15 in action.
Production Data
| Block Type | Specification（mm） | Qty/Pallet | Qty/Hour | Qty/8 Hours |
| Hollow Block | 400*200*200 | 8 | 1440 | 11520-15360 |
| Solid Brick | 240*115*53 | 42 | 10080 | 60480-80640 |
| Holland Paver | 200*100*60 | 28 | 5040 | 40320 |
| Zigzag Paver | 225*112.5*60 | 24 | 4320 | 34560 |
Product Detail
Block Display
The QT8-15 produces a superior range of porous hollow blocks ideal for drainage-friendly applications such as landscaping, parking lots, and ecological projects. The display showcases permeable hollow blocks, standard hollow blocks, solid bricks, and pavers—each featuring clean edges, uniform density, and precise dimensions. Thanks to the cast vibration table and precision guiding system, every block achieves exceptional compressive strength, high permeability, and excellent surface finish. Available in various sizes, cavity configurations, and colors with quick mold changes, the display demonstrates the machine's versatility. These durable, eco-friendly blocks meet international quality standards for sustainable construction worldwide.
Product Display
The QT8-15 product display showcases the machine's exceptional output range and hydraulic precision. Featured prominently are porous hollow blocks, standard hollow blocks, solid bricks, and paving stones—each exhibiting clean edges, uniform density, and precise dimensions. The display highlights the cast vibration table, PLC central control, and precision guiding system that ensure superior compaction and consistent quality. Also demonstrated is the machine's versatility through quick mold changes, allowing production of various cavity configurations, sizes, and colors.
| FAQ |
|
1.What is the QT8-15? The QT8-15 is a hydraulic, high-efficiency block making machine specifically engineered for producing porous hollow blocks, standard hollow blocks, solid bricks, and pavers. It is available for factory direct sale, offering exceptional value with robust construction, advanced vibration technology, and PLC intelligent control. |
|
2.What is the guiding system? The precision guiding system uses hardened chrome-plated guide rods and heavy-duty linear bearings in a four-column design. It eliminates lateral play, maintains vertical alignment, and ensures consistent block dimensions. Self-lubricating bushings reduce maintenance requirements. |
|
3.What are porous hollow blocks? Porous hollow blocks (also called permeable or drainage blocks) are concrete blocks designed with interconnected voids that allow water to pass through. They are used for drainage-friendly applications such as parking lots, driveways, walkways, landscaping, and ecological projects to reduce surface water runoff and promote groundwater recharge. |
|
4.Is the machine fully automatic? Yes, the QT8-15 features a fully automatic PLC control system with HMI touchscreen for one-touch operation, recipe storage, and real-time monitoring. |
|
5.Can the QT8-15 produce both porous and standard blocks? Yes. With quick mold changes , the machine switches between porous hollow block molds and standard hollow block or solid brick molds. The PLC allows different vibration and pressure parameters for each product type. |
