Factory Assurance Compressed Block Production Machine QT10-15
This equipment transforms concrete from the storage hopper into dense, high-quality blocks through vibration and pressure. It produces any required block shape using standard concrete, offering excellent versatility for factory assurance compressed production. The QT10-15 machine ensures consistent output, making it a reliable main equipment solution for manufacturing various concrete blocks efficiently.
Model :
Yixin Machinery QT10-15Machine Dimension :
11500*4050*2800Pallet Size :
1100*880（mm）Cycle Time :
15-20（S）Vibration Force :
105(KN)Vated Pressure :
21（mpa）Power :
45.2(KW)Factory Assurance Compressed Block Production Machine QT10-15
Reference video of QT10-15 compressed block making machine
The QT10-15 machine produces compressed blocks of any required shape using only standard concrete. It supports quick mold changes for diverse designs including hollow, solid, interlocking, and paving blocks. Heavy-duty hydraulic compression ensures high density and uniform strength across all shapes. The automated cycle handles mixing, molding, and curing with minimal labor. This flexibility eliminates the need for specialized materials or multiple machines, making it ideal for projects demanding constant variation in block geometry while maintaining production efficiency and low operational costs.
Production Data
| Block Type | Specification（mm） | Qty/Palllet | Qty/Hour | Qty/Hours |
| Hollow Block | 400*200*200 | 10 | 1800 | 14400-19200 |
| Solid Block | 240*115*53 | 51-56 | 13440 | 74880-99840 |
| Holland Block | 200*100*60 | 35 | 6300 | 50400 |
| Zigzag Block | 225*112.5*60 | 30 | 5400 | 43200 |
Product Detail
Block Display
The PLC control unit of the QT10-15 machine manages all equipment actions and production processes with high precision. It coordinates material feeding, compression, block forming, and discharge automatically. The unit supports real-time diagnostics, parameter adjustments, and fault alerts for reliable operation.
Professional Shipping
The blocks stacker of the QT10-15 automatically collects freshly formed blocks from the production line. It gently lifts and transfers blocks onto sturdy pallets or stacking frames. The unit stacks layers in a stable, interlocking pattern, preventing shifting or damage during curing. It handles various block sizes without manual reconfiguration. An intelligent control system matches stacking speed with machine output for continuous flow. This stacker reduces labor needs, improves safety, and ensures uniform curing. It is a reliable solution for high-volume block production, minimizing breakage and maximizing yard space utilization.
| FAQ |
|
1.How long does the product production cycle typically take? Factory Assurance Compressed Block Production Machine QT10-15 can produce a variety of products including external wall blocks, internal wall blocks, PC stone permeable bricks, flower wall blocks, floor blocks, dike blocks, chain blocks, curbs, and other types of blocks.The production time for brick making machines is generally 25-30 working days, depending on the customer's production line requirements. |
|
2. How many days to change vibration box oil ,what kind of oil can be used inside? The hydraulic oil 68 degree can be used, the amount is from bottom 3cm. Strongly suggest 1 month change one time oil. |
|
3.What are the raw materials used in the production process of Yixin Machinery Factory Assurance Compressed Block Production Machine QT10-15? The raw materials utilized in the production process of Factory Assurance Compressed Block Production Machine QT10-15 primarily include sand, gravel, and cement. Additionally, this machine has the capability to incorporate a significant amount of industrial waste materials such as slag, coal gangue, clay, ceramisite, perlite, and others. |
|
4.What is the estimated date of shipment for the Factory Assurance Compressed Block Production Machine QT10-15 after mold confirmation? The estimated date of shipment for the Factory Assurance Compressed Block Production Machine QT10-15 is 25-30 working days following the confirmation of the mold. This timeframe allows for the necessary preparations, assembly, and quality checks to ensure that the machine is ready for dispatch and meets the customer's specifications. |
|
5. Can the Factory Assurance Compressed Block Production Machine QT10-15 be equipped with an additional device to produce various types of colored paving blocks?
Yes, the Factory Assurance Compressed Block Production Machine QT10-15 can indeed be upgraded or equipped with a secondary materials device that allows for the production of a wide range of colored paving blocks. |
