Easy Operation Automatic Heavy Duty Interlocking Block Making Machine QT8-15
The QT8-15 automatic heavy duty interlocking block making machine combines powerful performance with easy operation. Its user-friendly PLC control system simplifies the entire production process, from material batching and mould filling to vibration, pressing, and block ejection. Operators can quickly set parameters and switch moulds for different interlocking block designs. The machine features high-frequency vibration and strong hydraulic pressure for dense, uniform blocks with precise interlocking profiles. Robust construction ensures reliable continuous operation with minimal maintenance. Automated cycle reduces manual labor and errors, delivering consistent quality.
Model :
Yixin Machinery HD8-15Machine Dimension :
10800*3600*2800Pallet Size :
940*860(MM)Cycle Time :
11-25(S)Vibration Force :
95(KN)Vated Pressure :
21(MPA)Power :
46.2(KW)Easy Operation Automatic Heavy Duty Interlocking Block Making Machine QT8-15
Reference video of HD8-15 interlocking block making machine
The QT8-15 interlocking block making machine features a flexible feeding arm designed to push the material cart with increased stability. This mechanism ensures smooth, controlled movement of the material cart during the feeding process, preventing sudden jerks or misalignment. The flexible design absorbs shock and compensates for minor variations, maintaining consistent material distribution across the mould. This stable feeding action reduces spillage, improves fill accuracy, and enhances overall block quality. The durable feeding arm requires minimal maintenance and operates reliably under continuous production, contributing to efficient, high-output manufacturing of interlocking blocks.
Production Data
| Block Type | Specification（mm） | Qty/Pallet | Qty/Hour | Qty/8 Hours |
| Hollow Block | 400*200*200 | 8 | 1584 | 12672 |
| Solid Block | 240*115*53 | 42 | 11088 | 88704 |
| Holland Paver | 200*100*60 | 28 | 5544 | 44352 |
| Zigzag Paver | 225*112.5*60 | 24 | 4752 | 38016 |
Product Detail
Block Display
The QT8-15 interlocking block making machine utilizes a ninety millimeter diameter guide cylinder and four hundred millimeter height bushing to ensure stable synchronization when the tamper head and mould frame move up and down. This precision guiding system maintains perfect alignment during vertical movements, preventing lateral deviation that could compromise block dimensions. The robust bushing height provides ample support length, reducing wear and extending component service life. Reliable synchronization ensures consistent compaction force across all mould cavities, producing uniform interlocking blocks with accurate profiles. This durable guiding design enhances machine stability, reduces vibration, and supports continuous high-speed production.
Professional Shipping
The QT8-15 interlocking block making machine offers optional servo frequency modulation drive control for enhanced performance. This advanced system delivers fast vibration start, significantly shortening the molding cycle while providing more accurate control over vibration intensity and duration. The servo technology enables precise adjustments for different material mixes and block designs, ensuring optimal compaction and density. Quick response times reduce idle periods between cycles, increasing overall production efficiency. The precise vibration control minimizes material waste and produces blocks with uniform strength and surface quality, making the machine ideal for high-output manufacturing requiring consistent, reliable results.
| FAQ |
|
1.What types of products can be produced using Yixin Machinery Easy Operation Automatic Heavy Duty Interlocking Block Making Machine QT8-15?
Yixin Machinery Easy Operation Automatic Heavy Duty Interlocking Block Making Machine QT8-15 can produce a variety of products including external wall blocks, internal wall blocks, PC stone permeable bricks, flower wall blocks, floor blocks, dike blocks, chain blocks, curbs, and other types of blocks. |
|
2. What is the production capacity of the Yixin Machinery Easy Operation Automatic Heavy Duty Interlocking Block Making Machine QT8-15?
This machine can produce up to 1584 hollow blocks(400*200*200mm) per hour, making it a highly efficient and productive option for your paver block production needs. |
|
3.What are the raw materials used in the production process of Yixin Machinery Easy Operation Automatic Heavy Duty Interlocking Block Making Machine QT8-15, and can it incorporate industrial waste materials?
The raw materials utilized in the production process of Easy Operation Automatic Heavy Duty Interlocking Block Making Machine QT8-15 primarily include sand, gravel, and cement. Additionally, this machine has the capability to incorporate a significant amount of industrial waste materials such as slag, coal gangue, clay, ceramisite, perlite, and others. |
|
4.What are the payment terms?
The advance deposit paid by T/T is 30%,and the balance before t/ T loading is 70%，You can also choose other trading methods. |
|
5. How automated is the system? Do I need a lot of skilled workers to operate it? The machine uses a Siemens PLC automatic control system with a touchscreen interface. The entire process—from material batching to molding and pallet feeding—is automated. You typically only need 3 to 4 workers: one to monitor the control panel, one to operate the forklift for pallet handling, and one to manage the mixer and raw materials. No specialized technical skills are required beyond basic training. |
