Name: Heavy Duty High-precision Cement Pavement Block Forming Machine QT15-15
Availability: InStock

Heavy Duty High-precision Cement Pavement Block Forming Machine QT15-15

Reference video of Heavy Duty High-precision Cement Pavement Block Forming Machine QT15-15:

The QT15-15 is a heavy-duty, high-precision cement pavement block forming machine designed for large-scale production of quality pavement blocks. Featuring an advanced hydraulic system and intelligent PLC control, it ensures precise shaping, uniform density, and excellent surface finish. Its robust construction and high vibration force deliver reliable performance for continuous operation. Quick mold change enables flexible production of various pavement designs. A reference video is available to demonstrate the complete forming cycle, from material feeding to finished block output. Ideal for highways, plazas, and industrial paving projects seeking high precision and heavy-duty durability.

Production Data

Block Type	Specification（mm）	Qty/Pallet	Qty/Hour	Qty/8 Hours
Hollow Block	400200200	15	2750	22000
Solid Brick	24011553	84	20625	165000
Holland Paver	20010060	55	10890	87120
Zigzag Paver	225112.560	40	7920	63360

Product Details

The QT15-15 is equipped with a high-precision pressure meter designed for accurate monitoring of hydraulic system pressure during pavement block forming. This digital pressure meter provides real-time readings, ensuring consistent compression force across each molding cycle. The clear LCD display allows operators to easily adjust pressure settings for different block types and material mixtures. Overload alert and auto-shutoff features protect the machine from pressure spikes. Low maintenance design with sealed sensors ensures long-term reliability.
The QT15-15 is equipped with precision-engineered 400mm height guide bushes designed to ensure accurate vertical alignment during high-precision pavement block forming. Manufactured from high-strength alloy steel with a hardened inner surface, these guide bushes provide smooth, friction-free movement for the mold carriage. The 400mm length offers extended guidance, reducing lateral play and ensuring consistent block height, edge squareness, and surface flatness. Oil-impregnated bushings minimize lubrication needs while resisting wear from heavy loads and high-frequency vibration.
The QT15-15 is equipped with a large-capacity hopper designed for efficient feeding of cement, sand, and aggregate materials for pavement block production. Constructed from heavy-duty steel with wear-resistant linings, it ensures durability and smooth material flow. The hopper's generous volume reduces frequent refilling, improving production continuity and labor efficiency. An advanced vibration system prevents material bridging and ensures consistent discharge. Easy to clean and maintain, it supports quick material changes for versatile pavement block designs.

Block Display

The QT15-15 produces a superior range of chain bricks ideal for driveways, walkways, erosion control, and landscaping projects. The display showcases interlocking chain bricks, pavers, hollow blocks, and solid bricks—each featuring clean edges, uniform density, and precise dimensions. Thanks to the dynamic and static vibration table and air bag cushioning system, every brick achieves exceptional compressive strength and excellent surface finish. Available in various sizes, shapes, and colors with quick mold changes, the display demonstrates the machine's versatility. These durable, low-maintenance chain bricks meet international quality standards for residential, commercial, and infrastructure applications worldwide.

Block Type

The QT15-15 product display showcases the machine's exceptional output range and low-maintenance design. Featured prominently are chain bricks, interlocking pavers, hollow blocks, and solid bricks—each exhibiting clean edges, uniform density, and precise dimensions. The display highlights the dynamic and static vibration table, air bag cushioning system, and hydraulic unit that ensure superior compaction and consistent quality. Also demonstrated is the machine's versatility through quick mold changes, allowing production of various sizes, shapes, and colors.

FAQ

1.What routine maintenance is required?

Daily lubrication, hydraulic oil level checks, air bag pressure inspection, vibration motor checks, and cleaning of mold and pallet areas.

2.What products can the QT15-15 produce?

The QT15-15 produces chain bricks, interlocking pavers, hollow blocks, and solid bricks in various sizes, shapes, and colors. The dynamic and static vibration table ensures superior compaction for dense, durable products with precise dimensions.

3.What makes this machine "low-maintenance"?

The QT15-15 features accessible lubrication points, wear-resistant components, an air bag cushioning system that reduces mechanical stress, and simplified service access to all major parts. These design elements significantly reduce downtime and routine maintenance requirements compared to conventional chain brick machines.

4.How does the dynamic and static vibration work?

Dynamic vibration provides high-frequency excitation for rapid material consolidation, while static vibration applies sustained pressure for surface finishing and edge refinement. Both modes are programmable via PLC for different brick types.

5. How many days to change vibration box oil ,what kind of oil can be used inside?

The hydraulic oil 68 degree can be used, the amount is from bottom 3cm. Strongly suggest 1 month change one time oil.
