Fully Production Hydraulic Heavy Duty Dike Block Making Machine QT8-15
The QT8-15 dike block making machine delivers fully automated hydraulic production for heavy-duty water conservancy and infrastructure projects. Its powerful compression system forms dense, erosion-resistant blocks with precise dimensions and smooth surfaces. High-frequency vibration ensures thorough material consolidation, eliminating voids and achieving superior structural strength. The PLC-controlled cycle manages batching, molding, and ejection with consistent accuracy. Durable construction withstands continuous operation in demanding environments. Quick mould interchange supports various block profiles for riverbanks, slopes, and retaining walls. The machine maximizes output efficiency while maintaining reliable quality, reducing labor costs and project timelines significantly.
Model :
Yixin Machinery HD8-15Machine Dimension :
10800*3600*2800Pallet Size :
940*860(MM)Cycle Time :
11-25(S)Vibration Force :
95(KN)Vated Pressure :
21(MPA)Power :
46.2(KW)Fully Production Hydraulic Heavy Duty Dike Block Making Machine QT8-15
Reference video of HD8-15 dike block making machine
The QT8-15 dike block making machine incorporates a servo hydraulic system that delivers precise hydraulic pressure during all machine operations. This advanced system significantly reduces energy consumption by dynamically adjusting power output to match real-time demands, eliminating wasteful flow and pressure oversupply common in conventional hydraulics. The servo technology enables exceptionally accurate control over mould filling, compression, vibration, and ejection cycles. Faster response times and smoother movements improve block uniformity and surface finish while lowering operating costs. This energy-efficient solution makes the QT8-15 ideal for sustainable, high-precision production of heavy dike blocks.
Production Data
| Block Type | Specification（mm） | Qty/Pallet | Qty/Hour | Qty/8 Hours |
| Hollow Block | 400*200*200 | 8 | 1584 | 12672 |
| Solid Block | 240*115*53 | 42 | 11088 | 88704 |
| Holland Paver | 200*100*60 | 28 | 5544 | 44352 |
| Zigzag Paver | 225*112.5*60 | 24 | 4752 | 38016 |
Product Detail
Block Display
The QT8-15 dike block making machine achieves faster and more stable demolding through its advanced hydraulic ejection system. This system applies controlled, even force to release formed blocks from the mould without damage or distortion. Rapid demolding reduces cycle times, increasing overall production efficiency. The stable ejection process ensures blocks maintain sharp edges, smooth surfaces, and precise dimensions. Consistent demolding also minimizes product rejection rates and mould wear. This reliable feature supports continuous high-output manufacturing of dike blocks with excellent quality, making the machine ideal for demanding infrastructure projects requiring both speed and durability.
Exhibition Experience
The QT8-15 dike block making machine features long guide sleeves that deliver exceptional stability and balance during operation. These guiding bushes are designed with an adjustable raising and lowering function, effectively reducing friction and mechanical wear between moving parts. By minimizing direct contact stress, the system significantly extends the service life of critical components such as the tamper head and mould frame. The precise alignment ensures consistent block density and shape across every cycle.
| FAQ |
|
1.What types of products can be produced using Yixin Machinery Fully Production Hydraulic Heavy Duty Dike Block Making Machine QT8-15?
Yixin Machinery Fully Production Hydraulic Heavy Duty Dike Block Making Machine QT8-15 can produce a variety of products including external wall blocks, internal wall blocks, PC stone permeable bricks, flower wall blocks, floor blocks, dike blocks, chain blocks, curbs, and other types of blocks. |
|
2. What is the production capacity of the Yixin Machinery Fully Production Hydraulic Heavy Duty Dike Block Making Machine QT8-15?
This machine can produce up to 1584 hollow blocks(400*200*200mm) per hour, making it a highly efficient and productive option for your paver block production needs. |
|
3.What are the raw materials used in the production process of Yixin Machinery Fully Production Hydraulic Heavy Duty Dike Block Making Machine QT8-15, and can it incorporate industrial waste materials?
The raw materials utilized in the production process of Fully Production Hydraulic Heavy Duty Dike Block Making Machine QT8-15 primarily include sand, gravel, and cement. Additionally, this machine has the capability to incorporate a significant amount of industrial waste materials such as slag, coal gangue, clay, ceramisite, perlite, and others. |
|
4.What are the payment terms?
The advance deposit paid by T/T is 30%,and the balance before t/ T loading is 70%，You can also choose other trading methods. |
|
5. How automated is the system? Do I need a lot of skilled workers to operate it? The machine uses a Siemens PLC automatic control system with a touchscreen interface. The entire process—from material batching to molding and pallet feeding—is automated. You typically only need 3 to 4 workers: one to monitor the control panel, one to operate the forklift for pallet handling, and one to manage the mixer and raw materials. No specialized technical skills are required beyond basic training. |
