Premium Efficiency Automatic MP Series Planetary Precast Concrete Mixer
The MP series planetary precast concrete mixer delivers premium efficiency and fully automatic operation for high-performance concrete production. Its planetary mixing action ensures thorough, uniform distribution of aggregates, cement, water, and additives within short cycle times. The robust design handles harsh precast applications, including dry, semi-dry, and fluid mixes. Automatic controls monitor and adjust mixing parameters, reducing human error and improving batch consistency. Easy-to-clean surfaces and low maintenance requirements support continuous production. This mixer is ideal for precast plants demanding reliable, repeatable, and energy-efficient mixing of high-quality concrete.
Model :
Yixin Machinery MP Series Planetary Precast Concrete MixerPacking :
FilmTransaction Mode :
TT or 100%LCMinimum Order Quantity :
1 SetColor :
white and blueDischarge Port: :
Xiamen PortMaterial Science :
Q235 Steel ,handox steelPremium Efficiency Automatic MP Series Planetary Precast Concrete Mixer
Reference video of MP Series Planetary Precast Concrete Mixer
The MP Series planetary precast concrete mixer delivers premium efficiency through its advanced planetary mixing action, specifically engineered for materials with high viscosity and high solids content. The planetary gear system drives multiple mixing paddles along overlapping paths, ensuring thorough and homogeneous blending of even the toughest concrete mixtures. This design eliminates dead zones and accelerates mix uniformity, making it ideal for precast applications requiring consistent quality.
Tech Data
| Type | MP330 | MP550 | MP750 | MP1000 |
| Charging Volume（L） | 500 | 750 | 1125 | 1500 |
| Discharging Volume（KG） | 800 | 1200 | 1800 | 2400 |
| Discharging Volume（L） | 330 | 500 | 750 | 1000 |
| Mixing Blade（PCS） | 1*2 | 1*2 | 1*3 | 2*2 |
| Power of Mixing Motor（KW） | 15 | 18.5 | 30 | 37 |
Product Detail
Block Type
The MP Series planetary precast concrete mixer delivers premium efficiency through powerful shearing and kneading action. Its advanced mixing mechanism achieves several times higher efficiency than ordinary mixers, ensuring thorough and uniform material blending in less time. The planetary motion creates intense yet controlled force, rapidly breaking down agglomerates and coating every particle evenly. This high mixing performance significantly reduces cycle times while improving concrete consistency and strength, making it ideal for demanding precast applications where quality, speed, and energy efficiency are critical for continuous production.
Customer Access
The MP Series planetary precast concrete mixer features wide applicability, handling materials with viscosities as high as one million centipoise and solid content below ninety percent. This capability allows it to effectively mix extremely thick pastes, heavy mortars, and high-solid slurries that ordinary mixers cannot process. The robust planetary drive and powerful kneading action ensure uniform dispersion even under challenging conditions. Whether for specialized precast concrete, refractory materials, or adhesive mortars, this mixer delivers consistent results across a broad range of demanding recipes and industrial applications.
| FAQ |
| 1. What is the maximum output capacity per batch for this MP Series mixer??
The MP Series is available in several models. Batch capacities range from 500 liters to 1,500 liters per cycle, depending on the exact model. For example, the MP-750 produces 1125 liters of compacted concrete per batch. We can help you select the right size based on your precast production schedule and mold cycle time. |
|
2. How consistent is the mix quality from one batch to the next??
Consistency is one of the main advantages. The planetary action, combined with high-quality wear-resistant liners and precisely spaced mixing tools, achieves a coefficient of variation below 3% in most precast recipes. |
| 3. What kind of concrete can this mixer handle? Only dry cast, or also wet cast and zero-slump??
The MP Series is designed for versatility. It handles dry cast, zero-slump concrete, semi-dry mixes, and wet cast concrete very well. For zero-slump applications like block making, the planetary mixer provides excellent energy transfer to break down agglomerates. For wet precast, it mixes quickly without segregating the aggregates. Many customers use the same MP mixer for multiple product lines. |
| 4. Can it be integrated into an existing automated precast production line?
Yes. The MP Series has standard connection points for automated batching systems, water addition control, and discharge actuators. It supports PLC communication protocols such as Profibus, Modbus, and Ethernet/IP. Many customers retrofit the MP mixer into existing lines. |
| 5.How energy efficient is this mixer compared to other planetary mixers on the market?？
The MP Series is optimized for energy efficiency. The motor power is matched precisely to the mixing pan size and planetary drive ratio. For a typical 750-liter batch of semi-dry precast concrete, power consumption ranges from 11 to 15 kWh per cubic meter of output. This is about 15 to 20 percent lower than older planetary designs, thanks to reduced friction in the planetary transmission and improved mixing geometry. |
